High efficient PCBN internal grooving tool CBN cutting insert tool
overview
Polycrystalline cubic boron nitride PCBN tool: (for finishing)
(Note: no water can be added during use)
CBN superhard cutting tools are specialized in finishing, mainly
cutting all kinds of hardened steel, alloy steel, tool steel, die
steel, manganese steel-spring steel, bearing steel, chilled cast
iron, high chromium cast iron, gray cast iron, powder metallurgy,
Ni-based And various difficult-to-machine high-hardness steels with
CO-based superalloy Rockwell hardness between (HRC45-80°).
1. Convert hexagonal boron nitride (HBN) into cubic boron nitride
(CBN) under high temperature and high pressure.
2. The cubic boron nitride micro-nano crystal powder and the binder
are synthesized into polycrystalline cubic boron nitride (PCBN)
under high temperature and high pressure.
PCBN has strong chemical inertness and will not chemically react
with ferrous metals at high temperatures
1. For machining cast iron
2. For processing high hardness, high wear-resistant alloy cast
iron and casting high-speed steel
3. For machining hardened steel
4. For machining difficult-to-machine materials, such as:
superalloy, tungsten carbide, etc.
Processing material: It has extremely stable chemical properties
for ferrous metals, hardened steel (45-60HRC), bearing steel
(60-62HRC) high-speed steel (>62HRC) tool steel (57-60HRC),
chilled cast iron and Fine turning can realize the replacement of
grinding by turning, which greatly improves the processing
efficiency.
Processing life: fracture toughness, high hardness and toughness,
good wear resistance and strong collapse resistance.
Joeben provide different type of CBN insert to order, single tip,
multi tip, full faced and solid inserts, coating is available per
requriement.
We also offer re-sharpening service.
Application:
PCBN-Cubic Boron Nitride Blade (CBN) is mainly suitable for
processing of hardened steel, hard/grey cast iron, HSS roll,
sintered metal, high hardness materials
Features:
Excellent wear resistance
More cutting edges can reduce cutting costs
Ideal for finishing ductile cast iron and continuous cuts for
finishing hardened materials
| Material | CBN, PCBN, Carbide |
| OEM/ODM | Acceptalbe |
| Manufacture | Yes |
| No of Edge | 2-8 |
| Cutting Material | Hardened steel, cast iron, HSS roll, sintered metal, high hardness
mat |
| Package | 1pc/5pcs/10pcs per plastic box |
| MOQ | 2pcs |
| Delivery Time | 7-10 days |
| Advantage | Durable, Excellent surface finish, Reduce the cost |
Q:Are you Manufacture?
A:Yes, we are manufacture. we produce our “JOEBEN “brand tools for gurantee the quality.
We also trading related tools for customers because we are in these
field over 10 years, we are very familiar Chinese market tools. we
usually help our customer choose the best suitable related tools
for them.
Q: What is your delivery time?
A: Most of models are ex-stock, if out of stock,there usually need
about 3-5 days or 7-10 days.
Q: Can you produce non-standard tools?
A: Yes, we can produce non-standard tools as per your drawing.
We also can design tools for you as per your usage requirement
Q:What is your advantages?
A: We are factory who produce our own brand “JOEBEN” tools, we must gurantee our brand quality. Also, we have factory
price and fast delivery.
Our advantage:
- 3. World top level prodution equipment and rich experience team
ATTACTION:
- 1.Make sure work piece and machine are stable and use a precision
holder.
- 2.Please adjust the speed,feed and cutting depth according to
actual cutting conditions.
- 3.The milling conditions are for an end mill where the tool
overhang length is less than 4*D(mill diameter). When the tool
overhang length is longer, please adjust the speed,feed and cutting
depth.
