Solid Carbide Reamers Customized Cutter Tungsten Solid Carbide
Reamer
Feature:
This tapered end mill has a 0.25mm radius cutting tip and a 20mm
cutting length. The TiSiN coating provide great performance and
extended tool life.
Tapered CNC end mills with ZRN coating provide the extra length
needed to carve 3D shapes out of solid wood, plastic, foam and
other materials.
The tapered design provides added strength to the bit while still
maintaining a small radius at the bit's tip.
This unique design provides clearance when routing 3D profiles and
allows you to create complex carvings in all kinds of stock.
With the added TiSiN coating, the bit¡¯s lifespan and durability
are increased substantially avoiding unnecessary down time.
1. Fully enables running at rough machining parameters, resulting
in finish surface quality.
2. Excellent performance in machining titanium, stainless steel and
high temperature alloys.
3.The coating provides longer tool-life or increased
cutting-values.
4. Suitable for all types of steel or metal.
Original raw micro grain material, high hardness and T.R.S
a, Material: tungsten carbide
b, TRS: >3600 N/mm2
c, HRA: 91.8-92.4, HRC:45/55/60/65
d, Grain size: 0.2-0.6μm
e, Helix angle: 30°-45 °
Diameter of cutting edge: 0.2-0.9mm; 1-20mm
Size: Diameter 1.0mm-20mm standard and non-standard.
Cutting Form: Square,Ball nose, Corner Radius, Taper Flute, etc.
Type of flute: 2/3/4
End Mill Tool material composition:
1. Physical Properties:
a. Hardness greater than or equal to 92.6 HRA;
b. Density greater than or equal to 14.4g/cm³;
c. TRS greater than or equal to 3800 N/mm²;
d. Free of ETA phase condition;
e. No contamination by other materials;
f. Porosity = A02/ B00 / C00 ;
g. Uniform and consistent grain size. No grain size can be larger
than specified.
h. Chromium carbide grain growth inhibitor only.
2. All the tools of production, coatings are used in Germany,
Switzerland, processing equipment;
3. It's proposed cutting less than 65HRC;
| EDP No. | Dia(mm) | Angle | Flute Length(mm) | Flutes | Shank Dia(mm) | OverLength(mm) |
| 2207010605 | 0.4 | 90 | 8 | 2 | 4 | 45 |
| 2207010229 | 0.5 | 127 | 0.87 | 2 | 4 | 50 |
| 2207010160 | 0.5 | 90 | 5 | 2 | 4 | 50 |
| 2207010342 | 1 | 71 | 9.94 | 2 | 4 | 50 |
| 2207010089 | 1 | 90 | 5.00 | 2 | 4 | 50 |
| 2207010085 | 1.2 | 120 | 5 | 2 | 4 | 50 |
| 2207010606 | 1.2 | 90 | 5.0 | 2 | 4 | 50 |
Super raw material
| HRC45 | HRC55 | HRC60 | HRC65 |
| YG10X | YG10.2 &WF25(Taiwan) | K44 & K40 (German) | H10F (Sweden) |
Grain Size:0.7um
Co:10 %
Flexural strength: 3320N/mm2 | Grain Size:0.6um
Co:10 %
Flexural strength: 4000N/mm2 | Grain Size:0.5um
Co:12 %
Flexural strength: 4300N/mm2 | Grain Size:0.5um
Co:10 %
Flexural strength: 4300N/mm2 |
1. Physical Properties:overview
a. Hardness greater than or equal to 92.6 HRA;
b. Density greater than or equal to 14.4g/cm³;
c. TRS greater than or equal to 3800 N/mm²;
d. Free of ETA phase condition;
e. No contamination by other materials;
f. Porosity = A02/ B00 / C00 ;
g. Uniform and consistent grain size. No grain size can be larger
than specified.
h. Chromium carbide grain growth inhibitor only.
2. All the tools of production, coatings are used in Germany,
Switzerland, processing equipment;
3. It's proposed cutting less than 65HRC;
German cobalt collar K44, cobalt 12%, tungsten 88%, tungsten
carbide sintered grain size of 0.4 m and cobalt collar K55, cobalt
10%, tungsten 90%, tungsten carbide sintered grain size of 0.2 m
tungsten steel bar as raw materials.
Q:Are you Manufacture?
A:Yes, we are manufacture. we produce our “JOEBEN “brand tools for gurantee the quality.
We also trading related tools for customers because we are in these
field over 10 years, we are very familiar Chinese market tools. we
usually help our customer choose the best suitable related tools
for them.
Q: What is your delivery time?
A: Most of models are ex-stock, if out of stock,there usually need
about 3-5 days or 7-10 days.
Q: Can you produce non-standard tools?
A: Yes, we can produce non-standard tools as per your drawing.
We also can design tools for you as per your usage requirement
Q:What is your advantages?
A: We are factory who produce our own brand “JOEBEN” tools, we must gurantee our brand quality. Also, we have factory
price and fast delivery.
Our advantage:
- 1. 10 years experience in carbide roll and cutting tool
manufacturing
- 2. From row material to tool produdtion.
- 3. World top level prodution equipment and rich experience team
ATTACTION:
- 1.Make sure work piece and machine are stable and use a precision
holder.
- 2.Please adjust the speed,feed and cutting depth according to
actual cutting conditions.
- 3.The milling conditions are for an end mill where the tool
overhang length is less than 4*D(mill diameter). When the tool
overhang length is longer, please adjust the speed,feed and cutting
depth.
